LTO 6S Enclosure with Balancer Compartment
3D model of LTO 6S enclosure with balancer compartment, front view, white color, with visible internal elements and ventilation holes.
Model details
- Access Free download
Description
Overview and production context
Introducing a 3D model enclosure specifically designed for LTO 6S battery packs (6 cells YinLong 66160). The enclosure has external dimensions of 160x110x70 mm and internal dimensions of 150x100x65 mm, ensuring an exact fit for your requirements. A separate rear balancer compartment (80x40x20 mm) is included with Ø 2 mm ventilation holes and mounting points for two M3 screws. Internal partitions securely hold the cells, and stops prevent them from shifting. The top cover features a 5x5 mm grid ventilation with a 5 mm offset for efficient cooling. Side panels have recesses for XT60 connectors (10 mm depth, 6 mm diameter). The bottom panel is prepared for 4 M4 screws with a 140x90 mm diagonal. The model has 3 mm wall thickness and R2 mm rounded corners for durability and aesthetics. Polarity follows Korean standards: positive on the left, negative on the right when viewed from the front.
How to use this model
Use cases, fit and pre-production checks
This model is ideal for 3D printing with PETG, offering high strength and heat resistance. Supports are recommended for overhangs like XT60 recesses and ventilation holes. Scaling is possible, but maintain wall thickness and mounting dimensions. The model is also excellent for game projects, AR/VR applications, or as a display piece in electronic catalogs. Its detailed and functional design can serve as a base for custom battery packs for e-bikes, e-scooters, or portable power supplies.
When placing the model in an interior scene or diorama, consider its precise dimensions and integration with other components. The smooth PETG finish provides a professional look. Note that the model is not animated or rigged, but its static form effectively conveys functionality and design.
FAQ
Answers for this exact model page
What are the dimensions of the enclosure and balancer compartment?
The external dimensions of the enclosure are 160x110x70 mm, and the internal dimensions are 150x100x65 mm. The balancer compartment measures 80x40x20 mm.
What design features are included for ease of use?
The enclosure features a ventilation grid on the top cover, recesses for XT60 connectors on the side panels, mounting points for M4 screws on the bottom panel, and internal partitions to secure the cells.
What material is recommended for 3D printing this model, and what printing considerations should be taken?
The model is optimized for printing with PETG. Supports are recommended for overhangs like XT60 recesses and ventilation holes to achieve the best print quality.
How is the polarity oriented in this enclosure model?
Polarity follows the Korean automotive standard (Hyundai/Kia): when viewed from the front, the positive terminal (red) is on the left, and the negative terminal (black) is on the right.
