Spring-loaded marker holder for robotic arm
3D model spring-loaded marker holder for robotic arm, side view
Model details
- Subcategory Factory equipment
- Access Free download
Description
Overview and production context
Introducing the 3D model of a spring-loaded marker holder designed for robotic arms. This holder features a height compensation mechanism that automatically adapts to surface irregularities through vertical movement of the marker assembly. The model has a universal mounting interface for standard cylindrical arms with a diameter of 25–30 mm and is designed for markers with a diameter of 15–17 mm. The spring mechanism with at least 10 mm travel and guides prevents tilting, ensuring stability.
How to use this model
Use cases, fit and pre-production checks
This 3D model is ideal for 3D printing with PLA. A wall thickness of at least 2 mm and infill of 20–30% are recommended. The model is optimized for printing, without decorative elements, focusing on manufacturability and ease of assembly. The STL format ensures compatibility with most 3D printers. The model can also be used in games, AR/VR applications, or as part of industrial visualization, demonstrating the functionality of robotic systems.
FAQ
Answers for this exact model page
What are the main advantages of this marker holder model?
The main advantage is the built-in spring mechanism with guides, which provides automatic compensation for surface height variations, ensuring a stable marker position.
What markers and arms is the holder designed for?
The holder is designed for markers with a diameter of 15–17 mm and has a universal mounting interface for standard cylindrical arms with a diameter of 25–30 mm.
What are the recommendations for 3D printing this model?
Printing with PLA is recommended, with a wall thickness of at least 2 mm and an infill of 20–30%. The model is designed for printability and ease of assembly.
Where else, besides 3D printing, can this model be used?
The model is well-suited for use in gaming projects, AR/VR applications, as well as for educational purposes and demonstrating the principles of robotic systems.
